Inspecting the Undercarriage for Wear on Used Excavators

Introduction

The undercarriage of an excavator is one of the most critical yet often overlooked components when evaluating a used machine. As the foundation that supports the entire weight of the equipment while providing mobility across various terrains, the undercarriage undergoes tremendous stress during operation. Proper inspection of undercarriage components can reveal valuable information about the machine's maintenance history, operating conditions, and remaining service life.

This comprehensive guide will walk you through the essential steps for inspecting undercarriage wear on used excavators, focusing on key components, measurement techniques, and evaluation criteria. Whether you're a contractor considering purchasing a used machine, a fleet manager maintaining equipment, or an equipment appraiser assessing value, understanding undercarriage wear patterns will help you make informed decisions.

Understanding Undercarriage Components

Before beginning any inspection, it's crucial to familiarize yourself with the major components that make up an excavator's undercarriage system:

1. Track Chains: The continuous loop of linked metal plates that wrap around the sprocket, idlers, and rollers to provide traction.

2. Track Shoes: The individual plates that bolt onto the track chains, featuring grousers (cleats) that dig into the ground.

3. Sprockets: The toothed wheels at the rear of the undercarriage that engage with the track chain links to propel the machine.

4. Idlers: The smooth wheels at the front of the undercarriage that guide the track and help maintain proper tension.

5. Rollers: The series of wheels mounted along the undercarriage frame that support the machine's weight and guide the track.

6. Carrier Rollers: The upper rollers that support the top section of the track chain.

7. Track Adjusters: Hydraulic or mechanical systems that maintain proper track tension.

Each of these components wears differently depending on operating conditions, maintenance practices, and machine hours. Understanding their normal wear patterns is essential for accurate assessment.

Preparation for Inspection

Before beginning the undercarriage inspection:

1. Position the Machine: Park the excavator on level, firm ground with adequate space to walk around it completely. Engage the parking brake and lower the bucket to the ground for stability.

2. Clean the Undercarriage: Request that the seller clean the undercarriage thoroughly before inspection. Built-up mud, rocks, and debris can obscure wear patterns and damage.

3. Gather Tools: Bring necessary inspection tools including:

- Calipers or wear gauge for measuring component dimensions

- Flashlight for illuminating dark areas

- Camera to document conditions

- Notebook for recording measurements

- Straight edge for checking track shoe wear

4. Review Documentation: Ask for maintenance records showing undercarriage service history, including any component replacements or adjustments.

Track Chain Inspection

The track chain consists of alternating link pairs (inner and outer) connected by pins and bushings. As these components wear, chain elongation occurs, which is the primary indicator of track chain wear.

Measuring Chain Elongation

1. Method 1: Pin-to-Pin Measurement

- Measure the distance between three consecutive pin centers (two link pitches)

- Compare to the original specification (typically around 8 inches for standard chains)

- Calculate percentage elongation: [(Measured length - Original length)/Original length] × 100

2. Method 2: Wear Gauge Measurement

- Use a dedicated track chain wear gauge that fits over the chain links

- Follow manufacturer instructions for determining wear percentage

Wear Limits:

- 0-3% elongation: Excellent condition

- 3-5%: Moderate wear, still serviceable

- 5-7%: Significant wear, consider replacement soon

- Over 7%: Excessive wear, immediate replacement recommended

Additional Chain Observations

- Check for cracked, bent, or missing links

- Inspect for uneven wear patterns indicating misalignment

- Look for excessive play between pins and bushings

- Examine for signs of improper lubrication (dry, rusted components)

Track Shoe Inspection

Track shoes experience wear primarily on the grousers (cleats) and the base material where they contact the ground.

Measuring Track Shoe Wear

1. Grouser Height Measurement

- Measure remaining grouser height at multiple points along the track

- Compare to original height specifications (typically 50-70mm when new)

- Calculate percentage wear: [(Original height - Current height)/Original height] × 100

2. Base Thickness Measurement

- Measure remaining material thickness between bolt holes and ground contact surface

- Compare to original specifications (typically 20-30mm when new)

Wear Limits:

- 0-25% wear: Excellent condition

- 25-50%: Moderate wear, still serviceable

- 50-75%: Significant wear, replacement recommended

- Over 75%: Excessive wear, immediate replacement needed

Additional Shoe Observations

- Check for cracked, bent, or missing shoes

- Inspect bolt holes for elongation or wallowing

- Look for uneven wear patterns indicating improper track tension or alignment

- Examine for signs of excessive side loading (uneven wear across shoe width)

Sprocket Inspection

Sprocket teeth engage with the track chain bushings to propel the machine. As both components wear, the engagement pattern changes.

Measuring Sprocket Wear

1. Tooth Profile Inspection

- Compare tooth shape to new sprocket specifications

- Look for hooked, pointed, or asymmetrical teeth indicating wear

- Measure tooth thickness at the pitch line (where chain engages)

2. Engagement Test

- Rotate the track slowly while observing sprocket-to-chain engagement

- Proper engagement should be smooth with minimal play

- Excessive play or skipping indicates worn components

Wear Indicators:

- Sharp, pointed teeth (rather than rounded)

- Asymmetrical wear patterns

- Visible notching or grooving on tooth faces

- More than 25% reduction in tooth thickness

Additional Sprocket Observations

- Check for cracked or broken teeth

- Inspect for signs of hardening or heat checking

- Look for uneven wear indicating misalignment

- Examine mounting surfaces for wear or damage

Idler Inspection

Front idlers guide the track and help maintain proper tension. They experience wear on both the tread surface and flanges.

Measuring Idler Wear

1. Tread Diameter Measurement

- Measure idler diameter at multiple points

- Compare to original specifications (typically 300-500mm for medium excavators)

- Calculate percentage wear

2. Flange Height Measurement

- Measure remaining flange height

- Compare to original specifications

Wear Limits:

- 0-10% diameter reduction: Excellent condition

- 10-20%: Moderate wear, monitor closely

- Over 20%: Excessive wear, replacement recommended

Additional Idler Observations

- Check for cracked or damaged flanges

- Inspect for uneven wear patterns

- Examine seals for leaks (grease or oil)

- Check bearings for play or roughness when rotated

Roller Inspection

Rollers support the machine's weight and guide the track. They experience wear on the tread surface and flanges.

Measuring Roller Wear

1. Tread Diameter Measurement

- Measure roller diameter at multiple points

- Compare to original specifications

- Calculate percentage wear

2. Flange Height Measurement

- Measure remaining flange height

- Compare to original specifications

Wear Limits:

- 0-10% diameter reduction: Excellent condition

- 10-20%: Moderate wear, monitor closely

- Over 20%: Excessive wear, replacement recommended

Additional Roller Observations

- Check for cracked or damaged flanges

- Inspect for uneven wear patterns

- Examine seals for leaks

- Check bearings for play or roughness when rotated

- Look for signs of improper alignment (excessive side wear)

Carrier Roller Inspection

Carrier rollers support the upper track section and experience less wear than bottom rollers but should still be inspected.

Measuring Carrier Roller Wear

Follow similar procedures as for bottom rollers, though wear limits may be slightly more lenient due to reduced loading.

Track Adjuster Inspection

The track adjuster maintains proper track tension through either hydraulic or mechanical systems.

Checking Track Adjuster Function

1. Hydraulic Adjusters

- Check for leaks at cylinder and connections

- Verify proper tension adjustment range

- Inspect grease fittings and lubrication points

2. Mechanical Adjusters

- Check threaded components for wear or damage

- Verify proper tension adjustment range

- Inspect grease fittings and lubrication points

Additional Adjuster Observations

- Check for bent or damaged components

- Inspect mounting hardware for tightness

- Look for signs of impact damage

- Verify smooth operation through full range

Track Tension Evaluation

Proper track tension is critical for optimal undercarriage life and machine performance.

Checking Track Tension

1. Standard Method

- Measure sag between front idler and first bottom roller

- Typical specification: 20-40mm for medium excavators

- Adjust if necessary following manufacturer procedures

2. Alternative Method

- Lift track slightly off ground at midpoint

- Proper tension allows about one shoe height of deflection

Consequences of Improper Tension

- Too Tight: Accelerated sprocket and bushing wear, increased rolling resistance

- Too Loose: Excessive track slap, accelerated link and roller wear, potential derailment

Undercarriage Frame Inspection

While inspecting undercarriage components, don't overlook the structural frame that supports everything.

Frame Inspection Points

1. Structural Integrity

- Check for cracks, bends, or welds in frame members

- Inspect for signs of impact damage

- Look for excessive rust or corrosion

2. Mounting Points

- Check roller and idler mounting brackets for wear or damage

- Inspect bolt holes for wallowing or elongation

- Verify all fasteners are present and properly torqued

3. Wear Protection

- Examine wear plates and liners for excessive wear

- Check wear strip condition where track chains contact frame

Assessing Operating Conditions

Undercarriage wear patterns can reveal much about how the machine was operated:

1. Abrasive Conditions

- Excessive wear on all components

- Polished appearance on metal surfaces

- Embedded abrasive material in components

2. Rocky Conditions

- Impact damage to shoes and links

- Chipped or broken grousers

- Dented or bent components

3. Muddy/Wet Conditions

- Accelerated corrosion

- Seal failures leading to bearing contamination

- Packed debris causing accelerated wear

4. Pavement Operation

- Concentrated wear on shoe surfaces

- Reduced grouser height

- Potential for overheating components

Calculating Remaining Undercarriage Life

Based on your inspection measurements, you can estimate remaining component life:

1. Component-Specific Life Estimates

- Compare current wear to typical replacement thresholds

- Consider operating conditions affecting wear rates

- Factor in maintenance history and lubrication practices

2. Cost Considerations

- Estimate replacement costs for worn components

- Compare to machine value and intended use period

- Consider downtime implications of future replacements

Documentation and Reporting

Thorough documentation of your inspection findings is essential for:

1. Purchase Decisions

- Comparing multiple machines

- Negotiating price based on undercarriage condition

- Planning for future maintenance costs

2. Maintenance Planning

- Scheduling component replacements

- Budgeting for undercarriage repairs

- Tracking wear rates over time

Recommended Documentation

- Detailed measurements of all critical components

- Photographs showing wear patterns and damage

- Wear percentage calculations

- Replacement cost estimates

- Overall condition assessment and recommendations

Conclusion

A thorough undercarriage inspection is one of the most valuable assessments you can perform when evaluating a used excavator. By systematically examining each component, measuring wear patterns, and understanding the implications of your findings, you can make informed decisions about equipment purchases, maintenance priorities, and operational practices.

Remember that undercarriage condition often reflects overall machine care—a well-maintained undercarriage typically indicates a machine that has received proper attention throughout its service life. Conversely, neglected undercarriage components may suggest broader maintenance issues that could affect other systems.

By applying the techniques outlined in this guide, you'll be equipped to assess undercarriage wear accurately, anticipate future maintenance needs, and ultimately maximize the value and performance of your excavator investments.
